The Eaton 93PM UPS is a three phase online UPS, with power ratings from 10 – 400 kW. The UPS is available in tower form factor and is compatible with Lithium-ion UPS batteries, which are 40 percent smaller than VRLA batteries and have twice the lifespan, saving money on battery replacement costs and extra square footage for battery cabinets. This UPS comes with Unity power factor (VA=W) 1.0

Key technologies: ABM battery management, Eaton’s Energy Saver System (ESS)

Applications: Suitable for commercial buildings, medium to larger enterprise data centers. For safety, energy efficiency and a low-carbon future. Also suitable for multi-tenant and colocation. For mission critical 24x7 uptime

Compliance with standards: CE, RoHS

Brochure: Download 93PM UPS brochure

Contact me about this solution

Overview Specifications Resources Support

Topology

Online

Power Rating range

10 kVA – 400 kVA

Form Factor

Tower

Now a complete solution

To replace the Eaton 9390 UPS

Explore model specs

Easy deployment

● Maximizes deployment flexibility with thermal management options, flexible configurability and full-service access from the front
● Simplifies installation by fitting perfectly in line or alongside any standard-depth rack

Interact with the 93PM UPS

Bundle up with PredictPulse!

Starting January 2022, PredictPulse Wireless will be installed at no extra charge for all 93PM UPS models! The best news is that Eaton service technicians will install and activate this service during startup using a cellular broadband modem/router, streamlining the setup process for customers; at no-charge for one year for products sold after January 1, 2022!

Learn more

93PM UPS videos

Ease of management

● Provides easier access to detailed status information
● Optimizes server virtualization through power management and connectivity software
● Increases uptime with 24x7 remote monitoring and reporting capabilities

See 93PM LCD touchscreen

"The 93PM runs so well that sometimes it makes you worry, is everything really ok? For me, more than anything else, is the peace of mind I now have that our operations will continue running. That is worth its weight in gold, because I like to sleep at night!”

Read success story.

Joseph Daniels, Chief Information Officer, Illinois State Treasurer

Lowest Total Cost of Ownership (TCO)

● Reduces power and cooling
● Conserves valuable data center floor space
● Reduces cost and unexpected future growth risks

Calculate TCO and download mobile app

Eaton lithium-ion batteries

The weight and dimensional benefits of lithium-ion battery cabinets create the optimal solution for your white or gray space.

Download

Eaton 93PM 160/200 kW UPS bypass integrated accessory cabinet (IAC-B)

Eaton 93PM 400 kW UPS bypass distribution integrated accessory cabinet (IAC-BD)

Eaton 93PM 400 kW UPS bypass integrated accessory cabinet (IAC-B)

Eaton 93PM UPS large integrated battery cabinet (IBC-L)

Eaton 93PM UPS large welded integrated battery cabinet (IBC-LW)

Eaton 93PM UPS power distribution integrated accessory cabinet (IAC-PD)

Eaton 93PM UPS small welded integrated battery cabinet (IBC-SW)

Warranty and service plans

Eaton's UPS warranty and service options provide the system uptime, convenience and value that is right for you and your business.

Review here

Specifications

Product snapshot

Power Rating	10-400kW
Voltages	480V, 415V, 400V, 380V, 220V, 208V
Frequency	50/60 Hz
Topology	Double conversion with optional Energy Saver System (ESS)
Efficiency	Up to 97% in double conversion Up to 99% in Energy Saver System
Scalability	480V model: up to 8 internal power modules 208/220V model: up to 10 internal power modules External parallel up to 8 UPSs
Configuration	Tower
Batteries	480V model: Internal batteries up to 50kW 415/400/380V model: Internal batteries up to 40kW 208/220V model: Internal batteries up to 60kW External battery options for all models

Full tech specs

Name: Eaton 93PM UPS
Brand: Eaton

Power modules

Power offering (kW)

10–200 kW in 5 kW increments at 208/220V

20–160 kW in 10 kW increments at 415/400/380V

20–200 kW in 10 kW increments at 480V

200–400 kW in 50 kW increments at 480V

Note: optional internal redundancy available for all models

General characteristics

Efficiency in Energy Saver System (ESS)	Up to 99%
Efficiency in double-conversion mode	Up to 97%
Parallel capability	Up to eight distributed. Some restrictions may apply; contact factory for more information.

Input characteristics	480V models	400V models	208V models
Voltage	480/277V 4-wire 480V 3-wire	380/220V 4-wire 400/230V 4-wire 415/240V 4-wire	208/120V 4-wire 220/127V 4-wire
Voltage range:	+10%/-15%	+10%/-10%	+15%/-15% @ 208V +10%/-15% @ 220V
Frequency range	50/60 Hz	50/60 Hz	50/60 Hz
Power factor	> .99	> .99	> .99
Input current distortion	< 3% @ 100% load capacity	< 3% @ 100% load capacity	≤ 3.5% @ 100% load capacity

Battery options	480V models	400V models	208V models
Battery voltage	432V, 480V	480V	480V
Charging method	ABM® or float technology	ABM® or float technology	ABM® or float technology
Battery type	VRLA, AGM, Gel, Wet, Lithium, Flywheel, Super Caps	VRLA, AGM, Gel, Wet, Lithium, Flywheel, Super Caps	VRLA, AGM, Gel, Wet, Lithium

Output	480V models	400V models	208V models
Voltage	480 3-phase3-wire or 4-wire 208/120V with optional IAC-D, up to 200 kW	380V, 400V or 415V 3-phase 3-wire or 4-wire	208V or 220V 3-phase 3-wire or 4-wire
Frequency range	50/60 Hz	50/60 Hz	50/60 Hz
Regulation	±1% steady state	±1% steady state	±1% steady state
Voltage THD	< 1% (100% linear load) < 5% (non-linear load)	< 1% (100% linear load) < 5% (non-linear load)	< 1% (100% linear load) < 5% (non-linear load)
Load power factor range	Unity with the ability to support 0.8 leading to 0.8 lagging without de-rating	Unity with the ability to support 0.8 leading to 0.8 lagging without de-rating	Unity with the ability to support 0.8 leading to 0.8 lagging without de-rating

Certification	480V models	400V models	208V models
Safety	UL 1778, cULus, UL 924 Emergency, UL 924 Auxiliary	UL 1778, cULus	UL 1778, cULus
EMC	FCC Part 15 subpart B class A	FCC Part 15 subpart B class A	FCC Part 15 subpart B class A
Surge	IEC 61000-4-5	IEC 61000-4-5	IEC 61000-4-5

UPS Dimensions

Height: 74"

Depth: 42"

Width:

22”

20–150 kW (480V)\
20-120 kW (400V)
10–120 kW (208/220V)

32”

160–200 kW (480V)
120-160 kW (400V)

34.4"

10–160 kW (208/220V)

43.3"

10–200 kW (208/220V)

64"

250–400 kW (480V)

UL 924 certification

The 93PM meets the strict standards for UL 924 compliance for emergency lighting applications when ordered with an emergency lighting SKU. For more information, visit Eaton.com/UL924UPS.

Optional accessories

• Integrated maintenance bypass
• Integrated distribution cabinet (with input and output transformer options)
• Integrated power distribution cabinet
• Integrated parallel tie cabinets
• Integrated battery cabinet (small and large)
• Wall-mounted or floor mounted bypass
• Lithium battery cabinet
• Custom options available. Contact factory for more information.

Due to continuing improvements, specifications are subject to change without notice.
